How does laser scanning improve site engineering processes?
posted 25th September 2024
Accurate site information is essential to the success of any site engineering process. 3D laser scanning is used in numerous applications, but the technology proves highly valuable in engineering design.
We use our state of the art 3D laser scanners to record fine details and accurate measurements that were difficult to measure in the past. Traditional methods were time consuming and sometimes provided inaccurate measurements.
The 3D Laser Scanning Process
Once you have identified a potential area for your build, our team carries out your survey using our 3D laser scanners. A scan takes minutes to complete, capturing a large area. Depending on the area, our on-site survey is completed within the matter of a few days, typically taking a week or two to complete, taking our office work into consideration.
Point Clouds
The scanner unit projects a laser probe outward. When the probe reflects off a surface, it returns to the sensor located inside the scanner. This captures the distance, down to a few millimetres. We then use specialised software to convert the captured data into a digitised coordinate system, known as a point.
Our laser scanners can capture thousands of data points per second with precise measurements. The data points are then compiled and organised, using our specialist software, creating a visual representation, known as a point cloud.
Point clouds are mostly used as-built models for your project. When you know the exact location of potential issues, such as conduits, piping, fixtures, and devices, you can ensure your project goes ahead on schedule and budget, mitigating risks. When you use pre-engineering 3D laser scanning, you can plan and execute projects, while maintaining budgets and schedules.
Remote Capabilities
Since COVID-19, the demand for virtual site tours has grown in popularity, helping contractors and clients collaborate remotely. Our scanners can create three hundred and sixty degree horizontal and vertical panoramic views of each location we scan. Think of it as similar to Google street view. This adds clarity when discussing the project with clients regarding their innovative design and what areas need special considerations to achieve your end goals.
This information is used to answer contractor questions, discussing their concerns before the building begins, ensuring you always stay on budget and schedule.
Conclusion
3D laser scanning of your facility can help complete the design, using creative solutions you may have thought impossible in the past. The scan offers benefits for current and future projects. If you have any questions on how laser scanning improves site engineering processes or you want to book a survey, contact the experienced MB Survey Solutions team today.
